Pixel Pitch:4mm
Pixel: 4mm
LED array: SMD1921/SMD2727
Brightness: 4500-7000 nits
Refresh: 1920Hz / 3840Hz
Viewing angle: 140°/ 140° （50% brightness）​
Module size: 256mm(W) x 128mm(H)
Cabinet size: 512mm x512mm
Cabinet weight:9kg
Maintenance: Back
Pixel Pitch:4.8mm
Pixel: 4.8mm
LED array: SMD1921/SMD2727
Brightness: 4500-7000 nits
Refresh: 1920Hz / 3840Hz
Viewing angle: 140°/ 140° （50% brightness）​
Module size: 250mm(W) x 250mm(H)
Cabinet size: 500x500mm/500X1000mm
Cabinet weight:8kg/15.2kg
Maintenance: Back
Pixel Pitch:5mm
Pixel: 5mm
LED array: SMD2727
Brightness: 5000-7000 nits
Refresh: 1920Hz / 3840Hz
Viewing angle: 140°/ 140° （50% brightness）​
Module size: 160mm(W) x 160mm(H)
Cabinet size: 640mm x640mm
Cabinet weight:14kg
Maintenance: Back
Pixel Pitch:6mm
Pixel: 6mm
LED array: SMD2727/SMD3535
Brightness: 5500-7000 nits
Refresh: 1920Hz / 3840Hz
Viewing angle: 140°/ 140° （50% brightness）​
Module size: 192mm(W) x 192mm(H)
Cabinet size: 576mm x576mm/960mmX960mm
Cabinet weight:11kg/32kg
Maintenance: Back/Front optional
Pixel Pitch:8mm
Pixel: 8mm
LED array: SMD2727/SMD3535
Brightness: 5000-7000 nits
Refresh: 1920Hz / 3840Hz
Viewing angle: 140°/ 140° （50% brightness）​
Module size: 256mm(W) x 128mm(H)
Cabinet size: 1024mmX768mm/1024mm x 1024mm
Cabinet weight:32kg/42kg
Maintenance: Back/Front optional
Pixel Pitch:10mm
Pixel: 10mm
LED array: SMD2727/SMD3535
Brightness: 5500-7000 nits
Refresh: 1920Hz / 3840Hz
Viewing angle: 140°/ 140° （50% brightness）​
Module size: 320mm(W) x 160mm(H)
Cabinet size: 960mm x 960mm
Cabinet weight:32kg
Maintenance: Front / Back optional
Pixel Pitch:10mm
Pixel: 10mm
LED array: DIP346(RGB)
Brightness: 6500-10000 nits
Refresh: 1920Hz / 3840Hz
Viewing angle: 120°/ 60° （50% brightness）​
Module size: 160mm(W) x 160mm(H)
Cabinet size: 960mm x 960mm
Cabinet weight:35kg
Maintenance: Front & Back optional
960*960mm LED panel with fan design
Stadium LED panel
Outdoor LED Display
Available pixel pitch:
2.5mm
2.9mm
3mm
3.91mm
4mm
4.81mm
5mm
5.95mm
6mm
6.67mm
8mm
10mm(SMD/DIP)
16mm(DIP)
20mm(DIP)
​​
​​
Application:
Stadium
Outdoor advertising
Billboard
LED Sign
​
